Detail Information

Warranty:	1 Year	After-sale Service:	Online Technical Support
Project Solution Capability:	Graphic Design	Place Of Origin:	China
Brand Name:	Fanryn	Model Number:	Glass Wool Pipe Yf
Material:	Glass Wool	Color:	Yellow
Thickness:	25-90mm	Diameter:	18-529mm
Density:	48-80kg/m3	Package:	Plastic Bag Or Carton
Certificate:	CE	Water Absorption, By Volume:	0.2%
Facing:	Aluminum Foil Facing
Highlight:	3 Inch Copper Colored Aluminum Pipe , Air Conditioner Copper Colored Aluminum Pipe , Insulation Copper Colored Aluminum Pipe

Product Description

Factory price 3 inch colored aluminum air conditioner copper pipe insulation jacket

Recommend Thickness List(mm)
Pipeline System Type	The Thickness of glasswood pipe shell applied in different pipeline(mm)
Pipeline System Type	Liquid Temperature Range℃	Diameter of Branches Under 50mm	Under 25mm	32-50	64-100	125-150	Above 200mm
Air System Steaming and Water System High Temperature/High Pressure System	152-238	40	64	64	75	89	89
Medium Temperature/Medium Pressure System	122-151	40	50	64	64	75	75
low Temperature/low Pressure System	94-121	25	40	40	50	50	50
low Temperature System	49-93	13	25	25	40	40	40
Steaming Condensator of Watering System	Any Temperature	25	25	40	50	50	50

Facing For glass wool blanket :

Foil-Scrim-Kraft Facing
Alum Glass Cloth Facing

Specification:

Density(kg/m3)	Thickness(mm)	Length (mm)	Diameter (mm)
48-80	25-90	1000,1200	18-529

Factory price 3 inch colored aluminum air conditioner copper pipe insulation jacket

Product introduction of the Glass Wool Pipe

Glass wool Pipe Section is a kind of economical insulating material which is light and easy to install. This material has excellent performance of heat and sound insulation under both extremely high and low temperature conditions(.-85 degree to 454 degree) Therefore, glass wool section pipes are widely used on heat and sound insulation of ventilating ducts, industrial & civil heat supplying and all kinds of heating, cooling pipelines.

3 Inch Air Conditioner Copper Colored Aluminum Pipe Insulation Glass Wool Jacket 7

If you are interested in our products,please { click here }to see all the products

Q1: How to guarantee the quality of the products?

A1: Our experienced QC team will inspect product's quality in every process

Q2: How to pack exported goods?
A2: Our standard package is Vacuum plastic bag +woven bag (Standard Export Packing).

Q3: What is your lead time for one 40HC container order?
A3: Usual 10-15 work days after placing order.

Q4: What is your advantage on glass wool blanket?

A4: Our glass wool blanket can be freely cut in construction according the shape required.

Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?
A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.

If you have any other questions,please click here to "send an inquiry".

Tag:

Place of Origin:	China
Brand Name:	Fanryn
Certification:	CE
Model Number:	glass wool pipe yf

Minimum Order Quantity:	300.0 Pieces
Packaging Details:	Plastic bag or Carton
Supply Ability:	1000000 Piece/Pieces per Week
