Product Description:
Our Fiberglass Pipe Insulation is manufactured by Factory Direct, ensuring that you receive a top-quality product with no markups from middlemen. With its fireproof performance, this insulation guarantees that your pipes are protected from fire damage.
Not only does our insulation offer exceptional protection from fire, but it also serves as a reliable heat and sound insulator. By installing our Glass Wool Pipe Insulation, you can maintain a comfortable temperature in your home or office while reducing noise levels from your tube systems.
Our Fiberglass Piping Protection is easy to install, making it a cost-effective solution for your insulation needs. It is suitable for use in a variety of applications, including heating and cooling systems, plumbing, and more.
Overall, our Insulation for Tube Systems is a versatile and reliable option for those looking to protect their pipes from fire damage while also reducing heat loss and noise levels. Order now and experience the benefits of our Fiberglass Pipe Insulation for yourself!
Product parameter of the thermal insulation pipe
Recommend Thickness List(mm)
| Pipeline System Type |
The Thickness of glasswood pipe shell applied in different pipeline (mm) |
| Liquid Temperature Range ℃ |
Diameter of Branches Under 50mm |
Under 25mm |
32-50 |
64-100 |
125-150 |
Above 200mm |
| Air System Steaming and Water System High Temperature/ High Pressure System |
152-238 |
40 |
64 |
64 |
75 |
89 |
89 |
| Medium Temperature/ Medium Pressure System |
122-151 |
40 |
50 |
64 |
64 |
75 |
75 |
| low Temperature/ low Pressure System |
94-121 |
25 |
40 |
40 |
50 |
50 |
50 |
| low Temperature System |
49-93 |
13 |
25 |
25 |
40 |
40 |
40 |
| Steaming Condensator of Watering System |
Any Temperature |
25 |
25 |
40 |
50 |
50 |
50 |
Equivalent Thickness of Surface Cooling Prevention
| Environment Temperature |
Relative Humidity |
System Working Temperature |
| 2℃ |
7℃ |
13℃ |
| 38℃ |
50%-60% |
25 |
25 |
25 |
| 70% |
40 |
30 |
30 |
| 80% |
75 |
60 |
50 |
| 85% |
100 |
90 |
75 |
| 32℃ |
50%-60% |
25 |
25 |
25 |
| 70% |
25 |
25 |
25 |
| 80% |
50 |
50 |
40 |
| 85% |
80 |
75 |
60 |
| 27℃ |
50%-70% |
25 |
25 |
25 |
| 80% |
50 |
40 |
30 |
| 85% |
75 |
65 |
50 |
| 21℃ |
50%-70% |
25 |
25 |
25 |
| 80% |
50 |
40 |
30 |
| 85% |
75 |
50 |
40 |
If the humidity exceeds 90%, some cooling water will appeared on the surface. In this condition, adding the
waterproofing coat or PVC plastic shell if necessary.
Product size of the glass wool pipe
| Density(kg/m3) |
Thickness(mm) |
Length (mm) |
Diameter (mm) |
| 48-80 |
25-90 |
1000,1200 |
18-529 |
Product feature and application of the glass wool pipe
Glass wool pipes are widely used on heat and sound insulation of ventilating ducts, industrial & civil heat supplying and
all kinds of heating, cooling pipelines.
Applications:
The Fanryn Fiberglass Pipe Insulation is perfect for protecting hot/cold water pipes, HVAC ducts, cooling pipelines, and ventilation ducts. The glass fiber pipe wrap is easy to install, and it provides excellent insulation for your pipes. The insulation material is fireproof and can withstand high temperatures, making it perfect for use in industrial settings.
One of the main features of the Fanryn Fiberglass Pipe Insulation is its performance. The insulation material is fireproof, which makes it ideal for use in buildings where fire safety is a concern. The material also provides excellent insulation, reducing heat loss and saving energy costs. The fiberglass insulation for piping is also an excellent sound insulator, reducing noise levels and creating a more comfortable environment.
The Fiberglass Piping Protection is suitable for a wide range of applications. It is perfect for use in industrial settings, where hot or cold water pipes, HVAC ducts, and cooling pipelines are present. The insulation material is also ideal for use in commercial buildings, where ventilation ducts need protection. The insulation material is easy to install and can be cut to fit any size pipe or duct.
In conclusion, the Fanryn Fiberglass Pipe Insulation is an excellent product that offers excellent insulation for your pipes and ducts. The insulation material is fireproof, easy to install, and can save you on energy costs. If you are looking for a reliable and durable insulation material for your pipes or ducts, this product is an excellent choice.
Packing and Shipping:
Product Packaging:
- The fiberglass pipe insulation will be packed in cardboard boxes.
- Each box will contain 10 pieces of insulation.
- The dimensions of the box will be 24 x 18 x 12 inches.
- The weight of each box will be approximately 30 pounds.
Shipping:
- The product will be shipped via ground transportation.
- Shipping charges will be calculated based on the weight and destination of the order.
- The estimated delivery time is 5-7 business days.
- Customers will be provided with a tracking number once the order has been shipped.
FAQ:
Here are some frequently asked questions about our Fiberglass Pipe Insulation:
Q: What is the brand name of your Fiberglass Pipe Insulation?
A: Our Fiberglass Pipe Insulation is made by Fanryn.
Q: Where is your Fiberglass Pipe Insulation made?
A: Our Fiberglass Pipe Insulation is made in China.
Q: Is your Fiberglass Pipe Insulation certified?
A: Yes, our Fiberglass Pipe Insulation has an SGS fireproof certificate.
Q: What is the minimum order quantity for your Fiberglass Pipe Insulation?
A: The minimum order quantity for our Fiberglass Pipe Insulation is 1*40 ft container.
Q: What is the price for your Fiberglass Pipe Insulation?
A: The price for our Fiberglass Pipe Insulation is based on the specifications.
Q: How is your Fiberglass Pipe Insulation packaged?
A: Our Fiberglass Pipe Insulation is packaged in plastic bags.
Q: What is the delivery time for your Fiberglass Pipe Insulation?
A: The delivery time for our Fiberglass Pipe Insulation is 7-15 work days.
Q: What are the payment terms for your Fiberglass Pipe Insulation?
A: The payment terms for our Fiberglass Pipe Insulation are 100% TT.
Q: What is the supply ability for your Fiberglass Pipe Insulation?
A: Our Fiberglass Pipe Insulation has a supply ability of 300 containers per month.
