Aluminum Glass Cloth Foil Facing Material

Wearing Resistance Aluminum Glass Cloth Foil

Product Description

Product Introduction Of The ALUMINUM-GLASS CLOTH FOIL FACING

Aluminum-glass cloth foil facing is constructed using aluminum foil and fiberglass cloth which are laminated together using fire

retardant adhesive. Thanks to its high tensile strength and wearing resistance, it is extensively utilized as the barrier material,

and the pipeline wrapping material. It can also be used as the machine packing material to keep equipment away from vapor

and heat.

Product Parameter Of The ALUMINUM-GLASS CLOTH FOIL FACING

Product	Construction
FG-701	Foil: 7 micron/ Polyethylene/ 110 gsm fiberglass cloth (12x12 threads/cm)
FG-R701	Foil: 7 micron/ Flame retardant adhesive/ 110 gsm fiberglass cloth (12x12 threads/cm)
FG-R1801	Foil: 18 micron/ Flame retardant adhesive/ 95 gsm fiberglass cloth (8x8 threads/cm)

TYPICAL PHYSICAL PROPERTIES

Product	Basic weight (g/m²)	Tensile MD (n/25mm)	Tensile XD (n/25mm)	Bursting Strength(n)	WVTR (ng/N.s)	Reflectivity of Foil Surface	Temperature Resistance (℃)	Fire Rating
FG-701	160	310	190	125	5.75	95%	-29~ +66	-----
FG-R701	130	260	180	125	5.75	95%	-29~ +66	Class 1
FG-R1801	170	300	160	125	5.75	95%	-29~ +66	Class 1

Product Feature And Application Of The ALUMINUM-GLASS CLOTH FOIL FACING

Fiberglass cloth standard weight is 95gsm ~110 gsm

Typical width: 1.0m,1.1m,1.2m,1.25m,1.3m

Length: 100m,300m,1000m

Inner core: 76mm

APPLICATION:

Aluminum fiberglass foil suit for HVAC duct wrap, also used for on-line lamination with insulation materials of glass

wool, rock wool and mineral wool. The typical benefit is high tensile strength, excellent tear resistance.

Production Details Of The ALUMINUM-GLASS CLOTH FOIL FACING

High Tensile Strength Aluminum Glass Cloth Foil Facing Material Wearing Resistance 2

High Tensile Strength Aluminum Glass Cloth Foil Facing Material Wearing Resistance 3

Product Shipping Of The ALUMINUM-GLASS CLOTH FOIL FACING
